Aquaculture Fish Farm Waterproof Geomembrane Pond Liner HDPE High Density for Landfill Dam Soil Protection

Brand Name : Zhongloo

Model Number : ZL-TGM

Place of Origin : China

Payment Terms : T/T

Delivery Time : 6-10 days

Product name : geomembrane

Feature : Anti-UV, Durable, Waterproof, Eco Friendly

Application : Pond, reservoir,dam, fish farm, fish pond, aquaculture, landfill

Surface : smooth, single textured, double textured

Length : 50-100m

Width : 5-10m

Color : Black, white, customzied

Thickness : 0.3-3.0 mm, customized

Material : HDPE, LDPE, Lldpe, Other

Warranty : More than 5 years

Contact Now

Aquaculture Fish Farm Waterproof Geomembrane Pond Liner HDPE High Density for Landfill Dam Soil Protection

Geomembrane Pond Liner Description

Manufactured to GRI GM13 standards, this low-permeability synthetic geomembrane pond liner utilizes premium virgin polyethylene resin enhanced with carbon black, antioxidants, UV stabilizers, and anti-aging compounds. Engineered for exposed applications, geomembrane pond liner's smooth surface delivers exceptional ultraviolet resistance and impermeability. Geomembrane pond liner's primary applications include: solid waste landfills, mining operations, waste treatment facilities, aquaculture containment, water reservoirs, and hydraulic infrastructure.

Geomembrane Pond Liner Technical Parameter

ASTM Standard geomembrane pond liner

Spec
Properties		 Test method
ASTM		 GMS0.5 GMS0.75 GMS1.0 GMS1.25 GMS1.5 GMS2.0 GMS2.5
Thickness D5199 0.5mm 0.75mm 1.00mm 1.25mm 1.50mm 2.00mm 2.50mm
Density (≥ g/cc) D1505 0.940 0.940 0.940 0.940 0.940 0.940 0.940
Tensile Properties
(Each direction) (≥)
• yield strength
• break strength
• yield elongation
• break elongation		 D 6693
Type IV

8 kN/m
14kN/m
12%
700%

11 kN/m
20kN/m
12%
700%

15 kN/m
27 kN/m
12%
700%

18 kN/m
33 kN/m
12%
700%

22 kN/m
40 kN/m
12%
700%

29 kN/m
53 kN/m
12%
700%

37kN/m
67kN/m
12%
700%
Tear Resistance (≥) D 1004 64 N 93 N 125 N 156 N 187 N 249 N 311 N
Puncture Resistance (≥) D 4833 160 N 240 N 320 N 400 N 480 N 640 N 800 N
Stress Crack Resistance (≥) D 5397 500 hr. 500 hr. 500 hr. 500 hr. 500 hr. 500 hr. 500 hr.
Carbon Black Content D 1603 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0% 2.0-3.0%
Carbon Black Dispersion D 5596 Note(1) Note(1) Note(1) Note(1) Note(1) Note(1) Note(1)
Oxidative Induction Time (OIT) (≥)
(a)Standard OIT
- or -
(b)High Pressure OIT

D 3895

D 5885

100 min.

400 min.

100 min.

400 min.

100 min.

400 min.

100 min.

400 min.

100 min.

400 min.

100 min.

400 min.

100 min.

400 min.

Characteristics:

  1. Superior flexibility

  2. Extreme temperature tolerance (-70°C to 110°C)

  3. Chemical corrosion & aging resistance

  4. Exceptional environmental stress cracking (ESC) resistance

  5. High tensile strength with elongation capacity

Main Features:

  1. UV-resistant

  2. Impermeable barrier

  3. Reliable isolation

  4. High tear-resistant

  5. Puncture-proof

HDPE Geomembrane Application:
(1) Aquaculture:
Utilizing the geomembrane pond liner's anti-seepage properties, our geomembrane pond liner serves as:

  • Fish farm

  • Shrimp containment

  • Tank sealing

  • Recirculating aquaculture

(2) Landfill:
As the industry-standard geomembrane pond liner solution:

  • Base geomembrane pond liner for landfill bottoms

  • Capping geomembrane pond liner closure systems

  • Leachate collection geomembrane pond liner

  • Regulation pond geomembrane pond liner

(3) Water Treatment Systems:
Critical geomembrane pond liner applications include:

  • Power plant cooling geomembrane pond liner

  • Wastewater treatment geomembrane pond liner

  • Equalization basin geomembrane pond liner

  • Potable water geomembrane pond liner reservoirs

(4) Mining:
Heavy-duty geomembrane pond liner installations:

  • Heap leach pad

  • Tailings storage

  • Process solution

  • Sediment control

  • Acid rock drainage containmentAquaculture Fish Farm Waterproof Geomembrane Pond Liner HDPE High Density for Landfill Dam Soil Protection
